Features

The FISBA READYBeam™ is our answer to customers increasing demand for compact, powerful and reliable multicolor laser source that can be easily integrated into existing set-ups. The multicolor laser module is available in four main configurations and can easily be configured upon request. The turnkey, compact fiber coupled laser combiner is entirely manufactured in Switzerland.

  • Multicolor concept: 3 channels in one pre-aligned housing

  • Turn key solution with standard RS 485 interface

  • Singlemode fiber

  • Software control

  • Embedded TEC cooling

  • Embedded electronics

  • Individual control of each wavelength

  • Digital, analog and mixed modulation modes

Shop your READYBeam™ module here

FISBA READYBeam™ Bio1

READYBeam™ Bio1
Multicolor Lasermodule: 405 nm, 488 nm, 638 nm
Singlemode fiber, TEC controller, electronic driver. Incl. COC,
Test report and Manual

Technical Data

Wavelength: 405 nm, 488 nm, 638 nm

CHF 7’440.00

FISBA READYBeam™ Bio2

READYBeam™ Bio2
Multicolor Lasermodule: 488 nm, 520 nm, 660 nm
Singlemode fiber, TEC controller, electronic driver. Incl. COC,
Test report and Manual

Technical Data

Wavelength: 488 nm, 520 nm, 638 nm

CHF 7’440.00

FISBA READYBeam™ Ind1

READYBeam™ Ind1
Multicolor Lasermodule: 450 nm, 520 nm, 660 nm
Singlemode fiber, TEC controller, electronic driver. Incl. COC,
Test report and Manual

Technical Data

Wavelength: 450 nm, 520 nm, 660 nm

CHF 5’540.00

FISBA READYBeam™ Ind2

READYBeam™ Ind2
Multicolor Lasermodule: 450 nm, 520 nm, 638 nm
Singlemode fiber, TEC controller, electronic driver. Incl. COC,
Test report and Manual

Technical Data

Wavelength: 450 nm, 520 nm, 638 nm

CHF 5’540.00
Video file
Laser center wavelength tolerances: 405: 400–410 nm; 450: 440–460 nm; 488: 486–490 nm; 520: 515–530 nm; 638: 632–643 nm; 660: 655–665 nm

Power supply including RS-485 to USB adapter

Power supply kit 120V (USA)

Adapter kit for easy operation of the READYBeam™ from your PC or notebook. Available with different plugs for US, CH and GER (Schuko)

CHF 285.00

Power supply kit 230V (GER)

Adapter kit for easy operation of the READYBeam™ from your PC or notebook. Available with different plugs for US, CH and GER (Schuko)

CHF 285.00

Power supply kit 230V (CH)

Adapter kit for easy operation of the READYBeam™ from your PC or notebook. Available with different plugs for US, CH and GER (Schuko)

CHF 285.00

Technical Data

  Wavelength 1)
  405 nm 450 nm 488 nm 520 nm 638 nm 660 nm
FISBA READY BeamTM bio 1 1006061 x   x   x
FISBA READY BeamTM bio 2 1008062     x x x
FISBA READY BeamTM ind 1 1006062   x   x   x
FISBA READY BeamTM ind 2 1007773   x   x x

1) Laser center wavelength tolerances: 405: 400 – 410 nm ; 450: 440 – 460 nm; 488: 486 – 490 nm; 520: 515 – 530 nm; 638: 632 – 643 nm; 660: 655 – 665 nm

  Wavelength 1)
  405 nm 450 nm 488 nm 520 nm 638 nm 660 nm
FISBA READY BeamTM bio 1 1006061 x   x   x
FISBA READY BeamTM bio 2 1008062     x x x
FISBA READY BeamTM ind 1 1006062   x   x   x
FISBA READY BeamTM ind 2 1007773   x   x x
Output power calibrated values 2) 40 mW 40 mW 30 mW 30 mW 40 mW 40 mW
Power stability 8 h < 2%
Fiber type SM/PM, 3 µm core, end capped, APC Connector
Fiber cable length 1 m
Polarisation ratio 3) typ.17 dB
Spatial mode TEM 00
M2 < 1.1
Optical noise RMS, 20Hz – 20MHz typ. 0.2, max. 0.5 %
Laser operation modes CW, modulated
Digital modulation TTL input
Digital modulation frequencies 1 MHz
Digital rise time 10 – 90% 11 ns
Digital fall time 90 – 10% 11 ns
Analog modulation bandwidth 0 – 3.3 V input voltage
Analog modulation frequencies 20 KHz
Analog rise time 10 – 90% 12 µsec
Analog fall time 90 – 10 % 12 µsec
Laser safety class 3B
Max. storage temperature range - 10° C to + 60° C
Operational temperature range + 15° C to + 40° C
Power consumption typ. 5 W, max. 12 W
Temperature stabilization internal TEC controlled
Communication interface RS 485

1) Laser center wavelength tolerances: 405: 400 – 410 nm ; 450: 440 – 460 nm; 488: 486 – 490 nm; 520: 515 – 530 nm; 638: 632 – 643 nm; 660: 655 – 665 nm

2) linear calibrated power range from 10% to 100% (max)

3) min.13dB, max. 26 dB

To learn more about our multicolor laser combiner you can download the latest version of the product flyer here.

In our technical instructions you will find further details on safety, technical systems as well as installation and operating instructions.

Would you like to learn more about our fibre coupled laser module? Take a look at our latest White Paper: "The FISBA READYBeam™ - Robust, Compact Turnkey Three-Laser Source".


CFS phase modulating LCOS SLMs for holographic reconstruction in visual systems using a multicolor laser combiner.

To get your product up and running, you will need to download the installation software. Here can always find the latest version.

To control your READYBeam™ in an automated environment, there exists a third-party python module on GitHub that will get you started immediately.

Take a 3D look at our laser combiner! With the STEP file you can get an impression of the size and compactness of our turnkey laser source solution.

Applications

FISBA READYBeam Laseroptics Laser Combiner Applications Flow Cytometry

Flow Cytometry

The 2019 pandemic situation drove renewed interest and demand for Flow Cytometry solutions. Flow Cytometry has become a standard method in biotechnological research and in biotechnological process. It delivers up to 20 parameters with one measurement, and can be part of a highly automated system with over 100 events/sec. The resolution can be down to the singular cell level or to cell populations.

This makes Flow Cytometry one of the most powerful tools in modern Biotechnology with applications such as “rare event” detection in drug screening, biomarker discovery, or cell cycle analysis, to name just a few.

Proper illumination of the cells inside the flow chamber is a demanding task. The laser parameters, including the energy distribution, power stability, and overall beam quality need to meet stringent specifications to achieve clean signals for data analysis.

Besides the laser itself, you might be dependent on optical beam shaping elements for proper sample excitation within your instrument.

Our compact three-channel laser source READYBeam provides you an easy integration into existing and new Flow Cytometry systems for both fiber coupled and free space delivery options.

FISBA READYBeam LaserOptics Laser Combiner Applications Fluorescence Microscopy

Fluorescence Microscopy

Early origins of fluorescence in microscopy date back to the beginning of the 20th century. Since then, it has progressed a long way. A newer development involving fluorescence, super resolution, has significantly shifted the resolution of optical microscopes below the Abbe diffraction of approx. 300nm. A development that has only been possible with highly monochromatic and coherent laser light sources.

The READYBeam is such a light source, or more precisely it is a configurable three wavelength fiber coupled light source in an ultra-compact housing. A selection of different diode combinations are available and customized solutions possible.

The READYBeam delivers a Gaussian beam from single mode, polarization maintaining fiber. The fiber can be connected via an FPC/APC connector which makes alignment as easy as the Laser operation itself. The colors can be switched and modulated independently. While “off” the diode is in a true dark state and does not contribute to fluorophore bleaching.

FISBA READYBeam LaserOptics Laser Module Applications DNA sequencing

DNA Sequencing

Literally, the genomic age (genomics) started with the possibility to determine the linear base sequence of a single-stranded DNA. The genomic code is the blueprint for proteins that are built from amino acids, virtually participating in all cellular processes.

With highly automated fluorescence-based techniques more than 50,000 genomes could be deciphered so far, including the human genome which was completed in 2003. Our multi-wavelength laser module, the READYBeam, offers the most commonly used excitation lines for sequencing applications. They provide high quality TEM00 profiles, polarization extinctions ratios of 100:1, and alignment-free adjustment via an FCP/APC connector.

FISBA READYBeam LaserOptics Laser Module Applications Microfluidics

Microfluidics

The behavior of liquids in small channels differs from macroscopic systems, as the relationship of surface to volume increases. The physics of that behavior is described by microfluidic concepts.

Moreover, microfluidics is also a technology with the ultimate aim to replace complex and bulky laboratory processes on a miniaturized scale, Lab on a chip.

Small high precision optics and laser sources that complement microfluidic instrumentation are a key competence of FISBA.

With our turnkey laser module, you get a compact, easy-to-integrate and configurable laser source that can be customized to your desired requirements.

FISBA READYBeam LaserOptics Laser Module Applications Projection

Projection

Laser projection systems are a very general term for devices that use a laser source for pattern generation. Industrial applications of such lasers can be found in the textile, carpentry, boat & aircraft assembly, logistics, and construction industries.

FISBA laser modules and beam shaping optics can be customized to your specific application.

FISBA READYBeam LaserOptics Laser Combiner Applications Display Holography

Display & Holography

Light modulators play a central role in various application areas such as image display, wavefront control, general beam shaping, and holography.

This can be achieved either mechanically using micro-electronics-mechanical-systems MEMS, or optically by using liquid crystalline substances.

FISBA laser combiner are used in research applications and customized projects. We can customize it according to your requirements.
