Our lenses which fit your configuration

Material FAC Type EFL (µm) BFL (µm) NA Height (mm) Length (mm) Wavelength range (nm) EFL Range (mm)
1000557 FAC150_01 150 ±20 @940nm 30 ±15 @940nm 0.8 0.23 ±0.015 12.0 ±0.5 790 - 990 0.14 - 0.16
1001730 FAC150_01 150 ±20 @940nm 30 ±15 @940nm 0.8 0.23 ±0.015 2.0 ±0.2 790 - 990 0.14 - 0.16
1001731 FAC150_01 150 ±20 @940nm 30 ±15 @940nm 0.8 0.23 ±0.015 4.0 ±0.2 790 - 990 0.14 - 0.16
1001745 FAC200_01 200 ±30 @940nm 55 ±25 @940nm 0.8 0.33 ±0.03 2.0 ±0.1 790 - 990 0.18 - 0.21
1001746 FAC200_01 200 ±30 @940nm 55 ±25 @940nm 0.8 0.33 ±0.03 3.0 ±0.1 790 - 990 0.18 - 0.21
1001747 FAC200_01 200 ±30 @940nm 55 ±25 @940nm 0.8 0.33 ±0.03 4.0 ±0.1 790 - 990 0.18 - 0.21
1001748 FAC200_01 200 ±30 @940nm 55 ±25 @940nm 0.8 0.33 ±0.03 3.5 ±0.1 790 - 990 0.18 - 0.21
1001749 FAC200_01 200 ±30 @940nm 55 ±25 @940nm 0.8 0.33 ±0.03 2.5 ±0.1 790 - 990 0.18 - 0.21
1001753 FAC200_01 200 ±30 @940nm 55 ±25 @940nm 0.8 0.33 ±0.03 13.0 ±0.1 790 - 990 0.18 - 0.21
1004313 FAC200_01 200 ±30 @940nm 55 ±25 @940nm 0.8 0.33 ±0.03 15.0 ±0.1 790 - 990 0.18 - 0.21
1004572 FAC200_01 200 ±30 @940nm 55 ±25 @940nm 0.8 0.33 ±0.03 4.5 ±0.1 790 - 990 0.18 - 0.21
1001751 FAC200_02 200 ±30 @808nm 54 ±25 @808nm 0.8 0.33 ±0.03 2.5 ±0.1 750 - 850 0.18 - 0.21
1000534 FAC300_01 300 ±70 @940nm 70 ±30 @940nm 0.8 0.5 ±0.01 12.0 ±0.05 790 - 990 0.29 - 0.33
1000537 FAC300_01 300 ±70 @940nm 70 ±30 @940nm 0.8 0.5 ±0.01 3.0 -0.1/-0.2 790 - 990 0.29 - 0.33
1000561 FAC300_01 300 ±70 @940nm 70 ±30 @940nm 0.8 0.5 ±0.01 4.0 ±0.1 790 - 990 0.29 - 0.33
1001757 FAC300_01 300 ±70 @940nm 70 ±30 @940nm 0.8 0.5 ±0.01 2.2 ±0.1 790 - 990 0.29 - 0.33
1001758 FAC300_01 300 ±70 @940nm 70 ±30 @940nm 0.8 0.5 ±0.01 4.2 ±0.1 790 - 990 0.29 - 0.33
1001759 FAC300_01 300 ±70 @940nm 70 ±30 @940nm 0.8 0.5 ±0.01 2.5 ±0.1 790 - 990 0.29 - 0.33
1001762 FAC300_01 300 ±70 @940nm 70 ±30 @940nm 0.8 0.5 ±0.01 4.0 ±0.1 790 - 990 0.29 - 0.33
1001763 FAC300_01 300 ±70 @940nm 70 ±30 @940nm 0.8 0.5 ±0.01 3.5 ±0.1 790 - 990 0.29 - 0.33
1001766 FAC300_01 300 ±70 @940nm 70 ±30 @940nm 0.8 0.5 ±0.01 15.0 ±0.1 790 - 990 0.29 - 0.33
1001770 FAC300_01 300 ±70 @940nm 70 ±30 @940nm 0.8 0.5 ±0.01 4.0 ±0.1 790 - 990 0.29 - 0.33
1001773 FAC300_01 300 ±70 @940nm 70 ±30 @940nm 0.8 0.5 ±0.01 3.0 ±0.1 790 - 990 0.29 - 0.33
1001774 FAC300_01 300 ±70 @940nm 70 ±30 @940nm 0.8 0.5 ±0.01 4.5 ±0.1 790 - 990 0.29 - 0.33
1001765 FAC300_03 300 ±70 @940nm 70 ±30 @940nm 0.8 0.5 ±0.01 4.0 ±0.1 890 - 980 0.29 - 0.33
1001769 FAC300_04 310 +40/-20 @940nm 70 ±20 @940nm 0.8 0.5 ±0.01 4.2 ±0.1 890 - 980 0.29 - 0.33
1001776 FAC300_05 310 ±70 @1470nm 74 ±30 @1470nm 0.8 0.5 ±0.01 4.0 ±0.1 1450 - 1550 0.29 - 0.33
1001781 FAC300_05 310 ±70 @1470nm 74 ±30 @1470nm 0.8 0.5 ±0.01 3.5 ±0.1 1450 - 1550 0.29 - 0.33
1001772 FAC320_01 316 ±4 @940nm 70 +30/-0 @940nm 0.8 0.5 ±0.01 4.0 ±0.1 860 - 980 0.29 - 0.33
1001802 FAC360_01 360 ±40 @940nm 70 ±30 @940nm 0.8 0.6 ±0.03 2.0 ±0.1 790 - 990 0.34 - 0.38
1001799 FAC360_01 360 ±70 @940nm 70 ±30 @940nm 0.8 0.6 ±0.03 4.0 ±0.1 790 - 990 0.34 - 0.38
1001798 FAC360_01 360 ±70 @940nm 70 ±30 @940nm 0.8 0.6 ±0.03 12.0 ±0.05 790 - 990 0.34 - 0.38
1001803 FAC360_01 360 ±70 @940nm 70 ±30 @940nm 0.8 0.6 ±0.03 13.8 ±0.1 790 - 990 0.34 - 0.38
1001804 FAC360_01 360 ±70 @940nm 70 ±30 @940nm 0.8 0.6 ±0.03 3.0 ±0.1 790 - 990 0.34 - 0.38
1001801 FAC360_02 370 ±70 @1470nm 74 ±30 @1470nm 0.8 0.6 ±0.03 4.0 ±0.1 1450 - 1550 0.34 - 0.38
1001813 FAC450_01 450 ±40 @940nm 100 ±40 @940nm 0.8 0.75 ±0.03 11.5 ±0.1 790 - 990 0.42 - 0.46
1001814 FAC450_01 450 ±40 @940nm 100 ±40 @940nm 0.8 0.75 ±0.03 2.0 ±0.1 790 - 990 0.42 - 0.46
1001815 FAC450_01 450 ±40 @940nm 100 ±40 @940nm 0.8 0.75 ±0.03 4.0 ±0.1 790 - 990 0.42 - 0.46
1001817 FAC450_01 450 ±40 @940nm 100 ±40 @940nm 0.8 0.75 ±0.03 12.0 ±0.1. 790 - 990 0.42 - 0.46
1001818 FAC450_01 450 ±40 @940nm 100 ±40 @940nm 0.8 0.75 ±0.03 3.0 ±0.1 790 - 990 0.42 - 0.46
1000531 FAC600_01 600 ±70 @940nm 140 ±30 @940nm 0.8 1.0 ±0.015 5.5 ±0.1 790 - 990 0.56 - 0.62
1000535 FAC600_01 600 ±70 @940nm 140 ±30 @940nm 0.8 1.0 ±0.015 12.0 ±0.1 790 - 990 0.56 - 0.62
1000536 FAC600_01 600 ±70 @940nm 140 ±30 @940nm 0.8 1.0 ±0.015 14.0 ±0.1 790 - 990 0.56 - 0.62
1000539 FAC600_01 600 ±70 @940nm 140 ±30 @940nm 0.8 1.0 ±0.015 11.5 ±0.1 790 - 990 0.56 - 0.62
1000540 FAC600_01 600 ±70 @940nm 140 ±30 @940nm 0.8 1.0 ±0.015 10.3 ±0.1 790 - 990 0.56 - 0.62
1000566 FAC600_01 600 ±70 @940nm 140 ±40 @940nm 0.8 1.0 ±0.015 2.0 +0/-0.05 790 - 990 0.56 - 0.62
1000652 FAC600_01 600 ±70 @940nm 140 ±30 @940nm 0.8 1.0 ±0.015 8.0 ±0.1 790 - 990 0.56 - 0.62
1001852 FAC600_01 600 ±70 @940nm 140 ±30 @940nm 0.8 1.0 ±0.015 1.8 ±0.1 790 - 990 0.56 - 0.62
1001853 FAC600_01 600 ±70 @940nm 140 ±30 @940nm 0.8 1.0 ±0.015 11.3 ±0.05 790 - 990 0.56 - 0.62
1001854 FAC600_01 600 ±70 @940nm 140 ±30 @940nm 0.8 1.0 ±0.015 8.5 ±0.1 790 - 990 0.56 - 0.62
1001856 FAC600_01 600 ±70 @940nm 140 ±30 @940nm 0.8 1.0 ±0.015 11.5 ±0.1 790 - 990 0.56 - 0.62
1001866 FAC600_01 600 ±70 @940nm 140 ±30 @940nm 0.8 1.0 ±0.015 10.6 ±0.1 790 - 990 0.56 - 0.62
1001867 FAC600_01 600 ±70 @940nm 140 ±30 @940nm 0.8 1.0 ±0.015 4.0 ±0.1 790 - 990 0.56 - 0.62
1001872 FAC600_01 600 ±70 @940nm 140 ±30 @940nm 0.8 1.0 ±0.015 10.8 ±0.1 790 - 990 0.56 - 0.62
1001876 FAC600_01 600 ±70 @940nm 140 ±30 @940nm 0.8 1.0 ±0.015 2.0 +0/-0.05 790 - 990 0.56 - 0.62
1001889 FAC600_01 600 ±70 @940nm 140 ±30 @940nm 0.8 1.0 ±0.015 7.0 ±0.1 790 - 990 0.56 - 0.62
1004575 FAC600_01 600 ±70 @940nm 140 ±30 @940nm 0.8 1.0 ±0.015 11.5 ±0.1 790 - 990 0.56 - 0.62
1001865 FAC600_05 610 ±70 @1470nm 148 ±30 @1470nm 0.8 1.0 ±0.015 14.0 ±0.1 1450 - 1550 0.56 - 0.62
1001883 FAC600_08 600 ±30 @940nm 120 ±20 @940nm 0.8 1.0 ±0.015 11.0 ±0.1 790 - 990 0.56 - 0.62
1001888 FAC600_10 600 ±70 @450nm 140 ±30 @450nm 0.8 1.0 ±0.015 5.6 ±0.1 430 - 470 0.56 - 0.62
1001890 FAC600_10 600 ±70 @450nm 140 ±30 @450nm 0.8 1.0 ±0.015 11.5 ±0.1 430 - 470 0.56 - 0.62
1004348 FAC600_10 600 ±70 @450nm 140 ±30 @450nm 0.8 1.0 ±0.015 3.6 ±0.1 430 - 470 0.56 - 0.62
1004576 FAC600_13 590 ±70 @670nm 131 ±30 @670nm 0.5 0.8 ±0.05 6.0 +0/-0.05 620 - 750 0.56 - 0.62
1001894 FAC740_01 740 ±70 @940nm 70 ±30 @940nm 0.8 1.2 ±0.05 7.0 ±0.05 790 - 990 0.69 - 0.76
1001895 FAC740_01 740 ±70 @940nm 70 ±30 @940nm 0.8 1.2 ±0.05 12.0 ±0.05 790 - 990 0.69 - 0.76
1001896 FAC740_01 740 ±70 @940nm 70 ±30 @940nm 0.8 1.2 ±0.05 4.0 ±0.1 790 - 990 0.69 - 0.76
1004104 FAC740_01 740 ±70 @940nm 70 ±30 @940nm 0.8 1.2 ±0.05 6.0 ±0.1 790 - 990 0.69 - 0.76
1000525 FAC900_01 900 ±100 @940nm 90 ±40 @940nm 0.8 1.6 ±0.04 10.49 ±0.1 790 - 990 0.84 - 0.96
1000526 FAC900_01 900 ±100 @940nm 90 ±40 @940nm 0.8 1.6 ±0.04 3.0 ±0.05 790 - 990 0.84 - 0.96
1000532 FAC900_01 900 ±100 @940nm 90 ±40 @940nm 0.8 1.6 ±0.04 14.0 ±0.1 790 - 990 0.84 - 0.96
1000533 FAC900_01 900 ±100 @940nm 90 ±40 @940nm 0.8 1.6 ±0.04 12.0 ±0.1 790 - 990 0.84 - 0.96
1000541 FAC900_01 900 ±100 @940nm 90 ±40 @940nm 0.8 1.6 ±0.04 11.5 ±0.1 790 - 990 0.84 - 0.96
1001912 FAC900_01 900 ±100 @940nm 90 ±30 @940nm 0.8 1.6 ±0.04 4.0 ±0.1 790 - 990 0.84 - 0.96
1001914 FAC900_01 900 ±100 @940nm 90 ±40 @940nm 0.8 1.6 ±0.04 11.2 ±0.1 790 - 990 0.84 - 0.96
1001915 FAC900_01 900 ±100 @940nm 90 ±40 @940nm 0.8 1.6 ±0.04 6.0 ±0.1 790 - 990 0.84 - 0.96
1001916 FAC900_01 900 ±100 @940nm 90 ±40 @940nm 0.8 1.6 ±0.04 8.0 ±0.05 790 - 990 0.84 - 0.96
1001918 FAC900_01 900 ±100 @940nm 90 ±40 @940nm 0.8 1.6 ±0.04 10.3 ±0.1 790 - 990 0.84 - 0.96
1004334 FAC900_01 900 ±100 @960nm 90 ±30 @960nm 0.8 1.6 ±0.04 5.0 ±0.1 790 - 990 0.84 - 0.96
1001906 FAC900_04 900 ±100 @910nm 178 ±40 @910nm 0.8 1.5 ±0.02 10.8 ±0.05 790 - 990 0.84 - 0.96
1001913 FAC900_04 900 ±100 @910nm 178 ±40 @910nm 0.8 1.5 ±0.02 12.0 ±0.1 790 - 990 0.84 - 0.96
1001911 FAC900_05 900 ±50 @900nm 110 -25/+40 @900nm 0.8 1.5 ±0.03 10.4 ±0.05 790 - 990 0.84 - 0.96
1001689 FAC1100_01 1100 ±150 @940nm 110 ±40 @940nm 0.7 1.5 ±0.03 12.0 ±0.1 790 - 990 1.03 - 1.22
1001692 FAC1100_01 1100 ±150 @940nm 110 ±40 @940nm 0.7 1.5 ±0.03 13.8 ±0.1 790 - 990 1.03 - 1.22
1001693 FAC1100_01 1100 ±150 @940nm 110 ±40 @940nm 0.7 1.5 ±0.03 10.8 +0/-0.05 790 - 990 1.03 - 1.22
1001690 FAC1100_01 1100 ±150 @940nm 110 ±40 @940nm 0.7 1.5 ±0.03 11.0 ±0.1 790 - 990 1.03 - 1.22
1001691 FAC1100_01 1100 ±150 @940nm 110 ±40 @940nm 0.7 1.5 ±0.03 13.3 ±0.1 790 - 990 1.03 - 1.22
1001695 FAC1100_01 1100 ±150 @940nm 110 ±40 @940nm 0.7 1.5 ±0.03 3.5 ±0.1 790 - 990 1.03 - 1.22
1001694 FAC1100_02 1100 ±100 @940nm 152 ±30 @940nm 0.45 1.1 ±0.05 13.8 ±0.1 790 - 990 1.03 - 1.22
1000549 FAC1300_01 1300 ±150 @940nm 130 ±30 @940nm 0.7 1.8 ±0.05 12.0 ±0.1 790 - 990 1.222 - 1.33
1001716 FAC1300_02 1320 ±150 @1310nm 143 ±30 @1310nm 0.7 1.8 ±0.05 4.0 ±0.1 1200 - 1400 1.222 - 1.33
1001828 FAC1500_02 1500 ±150 @940nm 90 ±30 @940nm 0.7 2.0 ±0.03 11.5 ±0.5 790 - 990 1.41 - 1.53
1001829 FAC1500_02 1500 ±150 @940nm 90 ±30 @940nm 0.7 2.0 ±0.03 2.0 ±0.1 790 - 990 1.41 - 1.53
1004335 FAC1500_02 1500 ±150 @940nm 90 ±30 @940nm 0.7 2.0 ±0.03 5.0 ±0.1 790 - 990 1.41 - 1.53
